E6650A【肖曉：13377777186】 EXF Wireless Test Set for Femtocell
回收E6650A_二手安捷倫E6650A_收購E6650A
客服QQ:2090529353
地址：東莞市塘廈鎮花園中心
回收閑置儀器-沒有十全十美的產品，有百分之百的服務
全程優質服務，歡迎來電13377777186咨詢！
主要特性與技術指標
Reduce overall test time - See the latest enhancements
Handle high volumes with multi-DUT testing and parallel, sequential and hybrid methods in one chassis
Get ultra-fast processing and data transfers with a quad-core controller and high-bandwidth PXIe backplane
Test faster with advanced sequencing and single-acquisition multiple measurements (SAMM)
Scalable design allows up to 4 TRX per chassis to enable parallel testing of multiple femtocells; up to 6 GHz with 80/160-MHz bandwidth on each TRX
Easily test multi-format femtocell designs
Test LTE/LTE-A FDD, LTE/LTE-A TDD, W-CDMA/HSPA/HSPA+, GSM/EDGE-Evo and TD-SCDMA
Test WLAN 802.11a/b/g/j/p/n/ac
Get up and running faster with validated cellular and WLAN chipsets
Simplify test automation with standardized SCPI commands and reference drivers
Apply proven solutions to each line that produces femtocells using supported chipsets
Performance
Receiver EVM for 160 MHz 802.11ac: ≤ –43 dB (typical)
Absolute level accuracy, 380 MHz to 3.8 GHz: ≤ ±0.2 dB (typical)
Output power range, 380 MHz to 6 GHz: +5 to –130 dBm (typical)
描述
As small cells take off, keeping pace with growing demand and aggressive schedules is easier when you have access to deeper resources. The EXF is the industry’s first one-box tester dedicated to femtocell manufacturing, and it’s validated with the latest cellular and WLAN chipsets. It also delivers the speed, performance and scalability you need to ramp up rapidly and lower your cost of test.
